Lowrance StructureScan User Manual

15
StructureScan Specications
Power
Requirement
12 Volts
Voltage Input 10V - 17V
Transmit Power
WRMS: 500W RMS (800 kHz); 525W RMS (455kHz)
WPK: 4000W (800kHz); 4200W (455kHz)
Current Drain Max: .75A Typical: .60A Inrush: 4.7A pk
Fuse Type External: 3A Fast Acting Internal: 3.5 Slo-Blo
Coverage Area -3db and -10db
Transducer Cable 20 feet (6m)
Target Separation
1.5” (38.1mm)
Transducer
Frequency
455kHz and 800kHz
Communication Ethernet
Shared devices
supported
3
Weight
LSS-1 (1.8lbs)
Transducer (1.9lbs)
Transducer with bracket (2.55lbs)
Sidescan Specications
Max Range 455kHz (500ft — 250 per side) 800kHz (300ft —150 per side)
Max Speed 35 mph (56 kmh)
Mark objects 15 mph (24 kmh)
Optimum speed 10 mph (16 kmh) or less
Downscan Specications
Max Depth 100 ft (800kHz); 300 ft (455kHz)
Max Speed 55 mph (88 kmh)
Mark objects 35 mph (56 kmh)
Optimum speed 10 mph (16 kmh) or less

Lowrance StructureScan Specifications

General

Temperature Sensor	Yes
Frequency	455 kHz / 800 kHz
Cable Length	20 ft
Compatibility	Lowrance HDS Gen2, Gen3, Carbon, Elite Ti, Hook2
Mounting Type	Transom Mount
