Register Name
Register
Address
Bit Position
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
secondary_display_
direct_access_string
200
0x00C8
sec_display_direct_access_string
–
207
0x00CF
The string will be displayed with the 4x16 segment digits of the
secondary display.
The string will be updated if the secondary_display_direct_access_enabled flag at the
config_flags register at address 192 (Table 22 at Page 33) is set.
 Up to 16 ASCII character (limited to characters from 0x20 to 0x5F) including a string
terminator (0x00) can be displayed. If a string is longer than 4 characters the
secondary display will work as a ticker.
Table 23: Secondary Display Direct Access String
