L-STAT User Manual 42 LOYTEC
Version 1.0 LOYTEC electronics GmbH
Table 30 below shows possible values for the semantic meaning used in the configuration
for display values (Table 28 on Page 39) and set points (Table 29 on Page 41).
Primarily the semantic meaning field defines a text that is displayed along with a display
value or a set point. Additionally for display values it defines the internal sensor_value that
is displayed when the DSEU or DSSA bit is set. For examples on how to use the semantic
meaning field in the configuratiuon registers please see Table 31 at Page 43 for example
configurations.
Semantic Meaning Value
Description
Secondary Display Text
0x00
None (unconfigured)
0x01
Internal Temperature abs.
R O O M
0x02
Internal Temperature rel.
∆ S P T
0x03
External Temperature
O U T
0x04
Relative Humidity
H U M
0x05
Dew Point
D E W
0x06
Luminance (lx)
L U X
0x07
Amount CO
2
C O 2
0x08
Differential Pressure
P R E S
0x09
Flow
F L O W
0x0A
Valve Position
V A L V
0x0B
Fan Stage
F A N
0x0C
Heat/Cool Stage
H & C
0x0D
Brightness (%)
B R %
0x0E
Supply Voltage
2 4 V
0x0F
CPU voltage
C P U
0x10
CPU temperature
C P U
0x11
Room ID
R O O M
0x12
Damper Position (%)
D A M P
0x13
Reheat (%)
H E A T
0x14
Discharge Temperature
D I S
Table 30: Semantic Meaning
