pg. 11
Input Voltage 220 - 240 VAC ( 50 - 60 Hz )
Power Consumption
When Using
Less than 80W
2-3. Fuse Check
When there is no spare fuse offered along with the device, the fuse to change should A
fuse should be established in the fuse holder located in the upper part of the power
switch on the back board. When replacing fuses, if no spare fuses were offered with
the unit, the replacement fuse should match the properties listed in the fuse holder
(250 VAC, 3.15 A type T 5 × 20 mm).
2-4. Power Cable
In accordance with International Safety Standards, the LPT 3000’s power cable uses 3
lines including ”Ground.” When connected to a power outlet, the cable grounds a
cabinet of the unit.
2-5. Environment Conditions
WARNING !
To prevent the danger of a fire, please use only the recommended
fuses. Using a fuse with a different power rating may cause serious
damage to the spectrum analyzer.
Please u
se a grounded power cable with three lines, or connect the
spectrum analyzer to a protective “Ground” line. Operating the unit
without following these requirements may put you at risk of an electric
shock.
It is also important to check the source voltage
because if it exceeds the
standard recommended value, the spectrum analyzer might get
damaged permanently or catch fire.
