pg. 57
■
Channel Power
It calculates power and power spectrum density on a channel bandwidth
designated by a user. A marker on the display indicates the end of the channel
bandwidth. The marker selects Channel Power, and can be established as a Meas
Setup menu. It operates on single or continuous sweep mode.
If you press Meas Set-up after selecting Channel Power, you can set the channel
power measurement parameter. If you press Meas Control after selecting Channel
Power, you can temporarily suspend or resume measurement or make conversion
between continuous or single sweep modes.
MEASURE >> Channel Pwr
■
Occupied BW
The basic value of measurement is 99% of occupied bandwidth power. The
measurement operates on single or continuous sweep mode.
If you press Meas Set-up after selecting Occupied BW, you can set the occupied
bandwidth power measurement parameter. If you press Meas Control after
selecting Occupied BW, you can temporarily suspend or resume measurement or
make conversion between continuous or single sweep modes.
MEASURE >> Occupied BW
5-12. Preset
PRESET key initializes the analyzer back to the factory default state. As for the set-up of the state of
a free set, please refer to the following table of conditions of free set. If you are to select Preset
(Factory), press SYSTEM >> Power On/Preset >> Preset Type (Factory).
[Table 5-1] Conditions of Free Set
Amplitude Unit dBm
Indication and Lattice Display On
Attenuation 30 dB
Center Frequency 1.5 GHz
