Chapter 7 Exclusive Functions for iS7 Inverter Control/Monitoring
7-21
(4) Monitoring the current trip status of iS7 inverter
PLC option card can monitor up to 4 active trips of iS7 inverter. If a further trip occurs, it will over-write the
oldest trip.
◎ iS7 inverter trip list
Trip
No.
Trip Type
Trip
No.
Trip Type
Trip
No.
Trip Type
Trip
No.
Trip Type
0 HW Diag 16 - 32 Opt1(Slot1) Trip 48 -
1 Arm Short 17 NTC 33 Opt2(Slot2) Trip 49 -
2 OC 18 Fan Lock 34 Opt3(Slot3) Trip 50 -
3 OV 19 IPO 35 IO Board Trip 51 -
4 External Trip 20 UL 36 Expansion IO Trip 52 -
5 - 21 PTC 37 - 53 -
6 Fuse Open 22 Para WR Trip 38 - 54 -
7 Ground Fault 23 Pre PID Fail 39 - 55 -
8 OH 24 - 40 Encoder Board Trip 56 -
9 Eth 25 - 41 Over Speed 57 -
10 OL 26 - 42 Speed Deviation
Trip
58 -
11 - 27 - 43 External Brake 59 -
12 - 28 - 44 - 60 BX
13 - 29 - 45 HW OCS 61 LV
14 PO 30 - 46 - 62 Lost Cmd
(Comm.)
15 IOL 31 - 47 - 63 Lost Cmd
(Keypad)
- - - - - - 255 No Trip
▶ Special D register of PLC for monitoring inverter trip information
Special Register Description
D4490 Inverter Trip Save Area 1
D4491 Inverter Trip Save Area 2
D4492
Inverter Trip Save Area 3
D4493
Inverter Trip Save Area 4
When the iS7 inverter is powered on, the special D register (D4490~D4493) for inverter trip monitoring is
initialized to 0x00FF. The order of storing inverter trip information is D4490 Î D4491 Î D4492 Î
D4493. Up to 4 inverter trips can be stored, and the 5
th
will overwrite D4490, and the 6
th
will overwrite
D4491. In this manner, new inverter trip data are stored in the special D register.
To Next Page
