Chapter 7 Exclusive Functions for iS7 Inverter Control/Monitoring
7-23
(5) Isolating PLC option output when the inverter is tripped by LV (Low Voltage)
As described in page 7-7, (6) Terminal output, the method of isolating PLC output when the inverter is
tripped by LV (Low Voltage) is described below with an exemplary program.
▶ Common area of inverter
Referring to the parameters (exclusively for monitoring) of inverter common area in the “App. 4-4, page 4,
Appendix,” the addresses of the common area of the inverter level type trip information are as follows.
Common Area
Address
Function Detailed Description
BIT0 BX
BIT1 LV
BIT2 Lost Command
BIT3 KPD Lost Command
BIT4 -
BIT5 -
BIT6 -
BIT7 -
BIT8 -
BIT9 -
BIT10 -
BIT11 -
BIT8 -
BIT9 -
BIT10 -
0x332
Level Type Trip
Information
BIT11 -
▶ Special D registers of PLC for inverter status monitoring corresponding to APO76 ~ 83
Register Use of the Register Remark
D4474
Data to inputted in the common area parameter
address set up by AP076 (PLC Rd Data 1).
Inverter Î PLC option
(Monitoring)
D4475
Data to inputted in the common area parameter
address set up by AP077 (PLC Rd Data 2).
Inverter Î PLC option
(Monitoring)
D4476
Data to inputted in the common area parameter
address set up by AP078 (PLC Rd Data 3).
Inverter Î PLC option
(Monitoring)
D4477
Data to inputted in the common area para3meter
address set up by AP079 (PLC Rd Data 4).
Inverter Î PLC option
(Monitoring)
D4478
Data to inputted in the common area parameter
address set up by AP080 (PLC Rd Data 5).
Inverter Î PLC option
(Monitoring)
D4479
Data to inputted in the common area parameter
address set up by AP081 (PLC Rd Data 6).
Inverter Î PLC option
(Monitoring)
D4480
Data to inputted in the common area parameter
address set up by AP082 (PLC Rd Data 7).
Inverter Î PLC option
(Monitoring)
D4481
Data to inputted in the common area parameter
address set up by AP083 (PLC Rd Data ).
Inverter Î PLC option
(Monitoring)
To Next Page
