2.6 Completing the Installation
Before replacing the cover on your computer, complete the checklist as
shown in Table 2.2.
After you verify all items on the checklist, follow these steps:
Step 1. Replace the cabinet cover on your computer.
Step 2. Plug in all power cords, and turn on power to all devices and
your computer.
Step 3. Wait for your computer to boot up.
Note:
To change default configurations of the Ultra320 SCSI host
adapters, refer to the Fusion-MPT Device Management
System User’s Guide.
2.7 Setting Up Integrated RAID (IR) Solution
The “R” at the end of a host adapter name indicates the board supports
the Integrated RAID solution. The Integrated RAID solution provides cost
benefits for the server or workstation market where the extra performance,
storage capacity, and/or redundancy of a RAID configuration are required.
The two components of the Integrated RAID solution are:
• Integrated Mirroring™ (IM) solution, which provides features of
RAID 1 and RAID 1E
• Integrated Striping™ (IS) solution, which provides features of RAID 0
Table 2.2 Host Adapter Installation Checklist
Verify Installation Procedures Done
Host adapter connection in PCI/PCI-X/PCI Express bus slot is
secure (level)
Internal SCSI bus connections are secure (pin-1 continuity)
External SCSI bus connections are secure
Proper SCSI bus termination established
Unique SCSI IDs set and recorded for each device
To Next Page
