Ultra320 SCSI Host Adapters 3-9
Version 2.3 Copyright © 2002–2004, 2006 by LSI Logic Corporation. All rights reserved.
Figure 3.4 illustrates the LSI21320 series of host adapter board.
Figure 3.4 LSI21320 and LSI21320-R Host Adapter Drawing
J1 – PCI and PCI-X
LSI53C1030
J2
Channel A
Ultra320 SCSI LVD/SE
J3
Channel B
Ultra320 SCSI LVD/SE
J6 for
Channels
A and B
J4
Channel A
Ultra320 SCSI LVD/SE
