3-14 Ultra320 SCSI Host Adapter Characteristics
Version 2.3 Copyright © 2002–2004, 2006 by LSI Logic Corporation. All rights reserved.
3.2 Host Adapter Characteristics
Tab l e 3. 2 shows the general characteristics for all Ultra320 SCSI
host adapters.
Each Ultra320 SCSI host adapter offers SureLINK Domain Validation
technology to ensure data integrity by intelligently validating the
compatibility of the SCSI domain. These adapters also utilize Fusion-MPT
architecture that allows for thinner drivers and better performance.
3.3 Technical Specifications
The design and implementation of the Ultra320 SCSI host adapters
minimize electromagnetic emissions, susceptibility to radio frequency
energy, and the effects of electrostatic discharge. The adapter carries the
CE mark, C-Tick mark, FCC Self-Certification logo, Canadian
Compliance Statement, Korean MIC, Taiwan BSMI, Japan VCCI, and
meets the requirements of CISPR Class B.
3.3.1 Electrical Characteristics
Tab l e 3. 3 lists the maximum power requirements for standard
Ultra320 SCSI host adapters, including SCSI TERMPWR, under
normal operation.
Table 3.2 Host Adapter Characteristics
Flash
ROM
1
1. For boot code and firmware.
Serial
EEPROM
2
2. For BIOS configuration storage.
LVD/S E
Signaling
Ultra320 SCSI
Data Transfers
SCSI
Features
SCSI
Termination
Yes Yes 16-bit SE
or LVD
interfaces
Up to 320 Mbytes/s as well as
Fast, Ultra, Ultra2, and Ultra160
speeds; Synchronous offsets up
to 62.
Plug and Play
Scatter/Gather
Activity LED
TERMPWR with
autoresetting
circuit breaker
