Ultra320 SCSI Host Adapters 3-7

Figure 3.3 illustrates the LSI20320IE series of host adapters. The

LSI20320ILE adapter uses a PCI low profile bracket.

Figure 3.3 LSI20320IE and LSI21320ILE Host Adapter Drawing

LSI53C1020A

Channel A

Internal SCSI Connector

HDR2 Connector for

Channel A

J1 – PCI Express x4 Edge Connector

Channel A

Ultra320 SCSI LVD/SE

PCIe

Bridge
