S100 PROFInet Option Manual
8
4 PROFInet Communication Related Keypad Parameters
To operate an S100 inverter using the PROFInet communication module, set DRV-06
(Cmd Source) to [4 Fieldbus]. Set DRV-07 (Freq Ref Src) to [8 Fieldbus] to provide a
frequency reference to the inverter using the PROFInet communication module.
Code
Parameter Name
Default
Description
CNF
30 Option-1 Type
-
When the S100 PROFInet communication
module is installed, the module type
PROFInetis automatically detected and
displayed.
Note 1)
DRV
06 Cmd Source
1 Fx/Rx-1
0
Keypad
1
Fx/Rx-1
2
Fx/Rx-2
3
Int 485
4
Fieldbus
5
UserSeqLink
07 Freq Ref Src
0 Keypad-1
0
Keypad-1
1
Keypad-2
2
V1
4
V2
5
I2
6
Int 485
8
FieldBus
9
UserSeqLink
12
Pulse
COM
06 FBus S/W Ver
-
-
09 FBus Led
-
-
10 opt para-1
0
IP - 1
11 opt para-2
0
IP 2
