8 Supported PROFIdrive Parameters
Parameters
PNU
R/W
Description
922
R
Displays the selected PROFIdrive Cyclic Telegram
type.
1 → Standard Telegram
100 → Vendor Specific Telegram
* This parameter does not support writing via
PROFIdrive protocol. Set this parameter using the
inverter keypad. Go to COM 22 “opt para-13,” and set
it to “0” to select “Standard Telegram,” and to “1” to
select “Vendor Specific Telegram.”
944
R
Fault message counter
The parameter value increases by 1 each time a fault
condition occurs. The controller, such as a PLC, on the
PROFInet is notified of the inverter’s fault condition by
this parameter.
947
R
Fault number
* Refer to <9 Fault Message Counter (PNU[944]) and
Fault Number (PNU[947])>.
953
R
Warning word
* Displays the “Warning information” parameter value at
communication address 0h0334.
964
R
An array of five 16-bit word values that expresses the
S100 communication module information.
0: Manufacturer (the PROFInet vendor ID “849” for
LSIS, as defined by the Profibus.org, is displayed
(referenced from communication address 0h351).
1. Device Type: “1” is displayed for S100 PROFInet
communication module.
2. Version: Displays the software version.
E.g.,) “102” for Version 1.2
3. Firmware Date (yyyy): Displays the year of the
software release.
E.g.,) “2015” for the year 2015
4. Firmware Data (dd/mm): Displays the date and
month of the software release.
E.g,) “2512” for December 25
965
R
Indicates the Profile ID.
(0h328 – Profile 3 v4.0)
