S100 PROFInet Option Manual
21
Bit
Name
Description
compatible parameter communication addresses.
2
Bit for displaying
“level type trip
information”
This bit is set to 1 when more than one bit in the “level
type trip information” parameter bit field is set to 1.
Otherwise, it is set to 0.
This bit references address 0h0332 in the inverter’s
compatible parameter communication addresses.
3
Bit for displaying
“H/W Diagnosis Trip
information”
This bit is set to 1 when more than one bit in the “H/W
Diagnosis Trip information” parameter bit field is set to 1.
Otherwise, it is set to 0.
This bit references address 0h0333 in the inverter’s
compatible parameter communication addresses.
4
Bit for displaying
“Warning
information”
This bit is set to 1 when more than one bit in the
“Warning information” parameter bit field is set to 1.
Otherwise, it is set to 0.
This bit references address 0h0334 in the inverter’s
compatible parameter communication addresses.
5 to 15
-
Reserved
7.2.6 Torque
The inverter’s output torque. Torque is expressed in percentages (%), and can be
increased or decreased by 0.1%.
Torque value is displayed correctly only if the inverter’s control mode is set to “Sensorless”
or “Vector.”
7.2.7 Current
The inverter’s output current. Torque is expressed in amperes (A), and can be
increased or decreased by 0.1 A.
7.2.8 Dummy
Not used
