S100 PROFInet Option Manual
30
11 Accessing S100 Inverter Parameters using the PROFInet Record
Data Object
Using the PROFInet Record Data object, you can access the S100 inverter
parameters for data reading and writing, without the PROFIdrive communication
protocol.
The inverter’s parameter data is assigned to the PROFInet Record Data from the
index address 0h5000. Using the PROFInet IO RW service, you can directly access
the addresses to perform reading and writing.
For example, Siemens PLC users may access the inverter’s parameter data mapped
to the PROFInet Record using “WRREC” and “RDREC” function blocks. Refer to the
user’s manual that that is supplied with the inverter for more information about the
inverter parameter data.
E.g.) The inverter’s common parameter address 0h0001 is assigned to a PROFInet
index address 0h5001.
