S100 PROFInet Option Manual
10
5 Keypad Parameters Related to PROFInet Communication Module
5.1 CNF Group
5.1.1 [CNF-30] Option-1 Type: the type of device installed in the
module slot 1
Automatically detects and displays the type of communication module installed.
“PROFInet” is displayed when a PROFInet communication module is installed in the
S100 inverter.
5.2 DRV Group
5.2.1 [DRV-06] Cmd Source: Command Source Selection
Selects the command source for the S100 inverter. Set the parameter to [4 FieldBus]
to set PROFInet communication as the command source.
5.2.2 [DRV-07] Freq Ref Src: Frequency Reference Source Selection
Selects the frequency reference source for the S100 inverter. Set the parameter to [8
FieldBus] to set PROFInet communication as the frequency reference source.
