S100 PROFInet Option Manual
20
“bits 0 to 2” and “bit 6” indicate the following communication module status, as
explained in <10. PROFIdrive Status Diagram>.
Status Word
Status
xxxx xxxx x1xx x000
“Switching On Inhibited”
xxxx xxxx x0xx x001
“Ready For Switching On”
xxxx xxxx x0xx x011
“Ready For Operation”
xxxx xxxx x0xx x111
“Operation”
Note
“X” in the bit setting example indicates that the bit can be set to either 0 or 1 without
affecting the control word bit settings.
7.2.3 Setpoint value
Frequency reference for inverter operation. Setpoint value is expressed in Hz, and
can be increased or decreased by 0.01 Hz.
7.2.4 Actual speed value
The inverter’s actual output frequency. Actual speed value is expressed in Hz, and
can be increased or decreased by 0.01 Hz.
7.2.5 Alarm Information
Bit
Name
Description
0
Bit for displaying
“latch type trip
information-1”
This bit is set to 1 when more than one bit in the “latch
type trip information-1” parameter bit field is set to 1.
Otherwise, it is set to 0.
This bit references address 0h0330 in the inverter’s
compatible parameter communication addresses.
1
Bit for displaying
“latch type trip
information-2”
This bit is set to 1 when more than one bit in the “latch
type trip information-2” parameter bit field is set to 1.
Otherwise, it is set to 0.
This bit references address 0h0331 in the inverter’s
