S100 PROFInet Option Manual
15
the PLC, and the command types are as follows. Refer to <7.2.1 Control word
(STW1)> for more information.
• NoQuickStop Command
• NoCoastStop Command
• SwitchOFF Command
• SwitchON Command
• OperationEnable Command
• OperationDisable Command
• QuickStop Command
• CoastStop Command
The following table lists status transition events and the inverter operations:
Source Status
Target Status
Event
Action (Inverter operation)
“Switch On
Inhibited”
“Ready For
Switching On”
"SwitchOFF"
and "NoQuickStop"
and "NoCoastStop"
None (Motor is stopped.)
“Ready For
Switching On”
“Switch On
Inhibited”
"QuickStop"
or
"CoastStop"
None (Motor is stopped.)
“Ready For
Switching On”
“Ready For
Operation”
"SwitchON"
None (Motor is stopped.)
“Ready For
Operation”
“Ready For
Switching On”
"SwitchOFF"
None (Motor is stopped.)
“Ready For
Operation”
“Operation”
"OperationEnable"
Motor is run.
“Operation”
“Ready For
Operation”
"OperationDisable"
Motor is stopped (the S100
inverter stops the motor
according to the ADV-8 “Stop
Mode” settings).
“Operation”
“Switch On
Inhibited”
"CoastStop"
Motor is stopped (Free Run
Stop).
“Operation”
“Switch On
Inhibited”
"QuickStop"
Motor is stopped (the S100
inverter stops the motor
according to the ADV-8 “Stop
Mode” settings).
