LSIS SV022iG5A-2 - Product Details

1-2
1.2 Product Details
z Appearance
z Inside view after front cover is removed
Refer to “1.3 front cover removal” for details.
Front cover:
Removed when
wiring
Bottom cover:
Removed when
wiring input power
and a motor
Status LED Display
Inverter
nameplate
4-Way button for
parameter setting
(Up/Down/Left/Right)
Control signal
Terminal
NPN, PNP
Select Switch
[ENT]
button
STOP/RESET
button
Inverter Ground
Terminal
RUN button
Power terminal
Cooling fan
