LSIS SV022iG5A-2 User Manual

8-30
8.24 Parameter read/write
Group Display Parameter Name Setting Range Default Unit
Function
group 2
H91 [Parameter read] 1
0 ~ 1
0
H92 [Parameter write] 1
0 ~ 1
0
 Used to read/write Inverter Parameters using remote keypad.
CAUTION
Take caution when Parameter write (H92) is executed. By doing this, parameters in inverter
are cleared and parameters in remote keypad are copied to inverter.
 Parameter read
Step Note Keypad display
1 Move to H91 code. H91
2 Press Enter (z) key once. 0
3 Press Up (S) key once. Rd
4 Press Enter (z) key twice. rd
5 H91 is displayed when Parameter read is finished. H91
 Parameter write
Step Note Keypad display
1 Move to H92 code. H92
2 Press Enter (z) key once. 0
3 Press Up (S) key once. Wr
4 Press Enter (z) key twice. Wr
5 H91 is displayed when Parameter read is finished. H92
Inverter
Remote
keypad
Parameter Write(H92)
Parameter Read(H91)

LSIS SV022iG5A-2 Specifications

General

Model	SV022iG5A-2
Type	Inverter
Frequency	50/60Hz
Series	iG5A
Control Method	V/F Control, Sensorless Vector Control
Cooling Method	Forced Air Cooling
Enclosure Rating	IP20
Rated Power (HP)	3
Output Frequency	0-400Hz
Protection Features	Overcurrent, Overvoltage, Overheat, Undervoltage
Operating Temperature	-10°C to +50°C
Storage Temperature	-20 ~ 65°C
Humidity	5 to 95% RH (non-condensing)
Altitude	Up to 1000m
Rated Power (kW)	2.2 kW
Input Voltage	200 ~ 240 VAC
Phase	3-phase
