5
2) Remote Cable (2M,3M,5M)
z Remote Cable Model Number
Model number Specification
64100001 INV, REMOTE 2M (SV-iG5A)
64100002 INV, REMOTE 3M (SV-iG5A)
64100003 INV, REMOTE 5M (SV-iG5A)
z Installation
1) Take off the top cover of the I/O board kit and remove the hole cover to connect remote cable
on the side.
2) Attach the top cover of the I/O board kit and connect the remote cable as shown below.
To Next Page
