Chapter 13 Installation and Wiring

13 12

(6) Distance with other device

To avoid radiation noise or heat, keep the distance between PLC and device (connector and relay) as far as

the following figure.

Device installed in front of PLC: 100 ㎜ or above

Device installed beside PLC: 50 ㎜ or above

100mm or above

50mm or above
