Chapter 5 Program Configuration and Operation Method
5- 27
Change the debug ↔ stop mode
It starts debug operation.
It starts the subroutine program.
Other operation is
identical to Step
Over.
It finished the subroutine program.
It operates to current cursor position.
Set/Removes current cursor position to break
points.
It displays list of breakpoints.
It specifies device value and number of scan.
(a) Set/Remove Breakpoints
▪ Sets breakpoint at current cursor position. After breakpoint setting, (breakpoint setting indicator) is
displayed.
(b) Go
▪ Run the program to breakpoint. At break-pointer (stop indicator) is displayed.
To Next Page
