LTE Touchclave Ecotech Series - Page 10

Touchclave Ecotech
10
Drain hose connections:
1. Plug push fit connector into the Drain connector at the rear of the machine.
2. Place end of drain hose into an open drain, ensuring the hose is not submerged into any
fluid in the drain and that the drain is fitted with a trap.
Open Drain
Drain Trap
Drain
hose
