Number of Lines (#104)
5-203
Valid Entries
3 lines for the PARTNER ACS processor module and 308EC module, plus 2 lines
per 206 or 200 module, plus 4 lines per 400 module
✔
Programming
(See Figure 2-3 on page 2-22 for the location of special programming buttons such
as
s and e on system phones.)
To assign lines to the system at initial system setup:
1. Press
f 0 0 s s # 1 0 4 at extension
10 or 11.
2. Enter two digits for the number of outside lines in the system that you want
to assign to all extensions or the main pool. For example, dialing
0 6
means that all extensions are assigned lines 1 through 6 or lines 1 through
6 are assigned to the main pool.
3. Select another procedure or exit programming mode.
