A-3
Other Specifications
Switch Fabric ● Full digital, nonblocking
Electrical
Specifications
● 35 Watts (120 BTUs/hr.) per ACS processor module during normal power
consumption
● 45 Watts (154 BTUs/hr.) per ACS processor module during maximum power
consumption
● 10 Watts (35 BTUs/hr.) per 400 module, normal and maximum power consumption
● 25 Watts (90 BTUs/hr.) per 206 module during normal power consumption
● 35 Watts (120 BTUs/hr.) per 206 module during maximum power consumption
● 30 Watts (105 BTUs/hr.) per 308EC module during normal power consumption
● 40 Watts (140 BTUs/hr.) per 308EC module during maximum power consumption
● U.S., Canada, and other 110V countries:
— ACS processor module and one 206 module (2-Slot carrier) = 2.3 Amps max.
current, full system capacity
— ACS processor module and four 206 modules (5-Slot carrier) = 4 Amps max.
current, full system capacity
● Countries using 220V:
— ACS processor module and one 206 module (2-Slot carrier) = 1.2 Amps max.
current, full system capacity
— ACS processor module and four 206 modules (5-Slot carrier) = 2 Amps max.
current, full system capacity
● 45 days to 6 months memory backup with 2 AAA-size standard alkaline batteries
(IEC LR03)
Processor Module
Specifications
● 68306 16 Mhz processor
● 512Kbyte RAM
● 512Kbyte FLASH ROM
● Polarity reversal detection on the CO line port
● Custom VLSI DSP ASIC—16bit, 52 Mhz
— VLSI = Very Large Scale Integration
— DSP = Digital Signal Processor
— ASIC = Application Specific Integrated Circuit
Extension Jack
Specifications
(206 module)
● Ringing voltage: +5VDC, -140 VDC peak to peak; trapezoidal wave shaping
● 35- to 38-Volt talk battery
● Ringing frequency: 20 Hz
Extension Jack
Specifications
(ACS Processor and
308EC module)
● Ringing voltage: +55VRMS Balanced ringing within a trapezoidal wave shaping
● 38- to 42-Volt talk battery
● Ringing frequency: 20 HZ
● Polarity reversal detection on the CO line port
● 56K modem bypass to the Power Fail Transfer (PFT) relays
PAGE Jack
Specifications
● Draws current on inner wire pair
● Provides paging contact closure on outer wire pair
● 600 Ohm impedance
Music-on-Hold Jack
Specifications
● Accepts 2 Volts at 50 Kohms maximum input
● 0 - 18 dB attenuation
