LUMENIS UltraPulse - Troubleshooting Guide

Troubleshooting Guide  97
UltraPulse
0637-129-01, Revision G
Troubleshooting Guide
If the instrument fails to operate properly, this troubleshooting guide will help
you to locate and correct the malfunction. First, please check for the following
items:
Electrical Power Source
Verify that the electrical disconnect switch, the circuit breaker, is turned on.
Laser Console Electrical
Verify that the laser is on and properly connected to an electrical service
outlet.
Delivery System Connection
Verify that the delivery system is properly connected.
External Door Interlock
If the external door interlock is used in conjunction with a remote switch,
verify that the external door interlock plug is inserted in the external door
interlock receptacle. Close the interlocked door.
Articulated Arm
Verify that the articulated arm is properly positioned.
Problem Probable Cause Solution
System does not turn
on. Control screen does
not illuminate.
The laser is not plugged in.  Place the laser main power circuit
breaker in the off (down) position,
insert the laser electrical plug into the
appropriate outlet, then place the laser
main power circuit breaker in the on
(up) position.
The building power (main electrical
service) is turned off.
 Turn on the building power.
The laser main power circuit breaker is
in the off (down) position.
 Place the laser main power circuit
breaker in the on (up) position.
The electrical outlet is defective.
 Use another outlet or have the outlet
professionally tested and, if appropriate,
repaired.
