22
8.3.2
Live Viewing
No
Item
Function Descriptions
1
Preview window
Display
the
screen
currently captured
by DC-W80
2
Automatic Image
Optimization
Automatically adjust the im
age to have the best
brightness and focusing pe
rformance
3
Freeze the
Freeze the current image on t
he screen
4
Lamp mode
toggle switch
Click lamp
mode toggle switch:
off /
brightness 1
/
brightness 2 / brightness 3
5
Rotate the image
Rotate the image: 0°
/ 90°
/ 180°
/ 270°
/
Flip
/
Mirror
.
6
Image Mode
toggle switch
Select Photo/T
ext/Gray Mode
7
Logout
Log out of the web page
8
Fold/Expand
Function Bar
Click to fold/expand the Function
Bar on the left
1
5
6
7
8
2
3
4
22
