48
Chapter 10
Packing the Machine
1.
Put the rem
ote control back to th
e holder.
2.
Fold back
the camera head
to align with the arm
.
3.
Turn the t
wo lamp arms
and the arm
of
camera head down and adjust
them to be paral
lel with the platform
.
4.
Put the lens cap o
n the cam
era head.
5.
Finally, fold the m
achine as
in the following f
igure.
48
