Lumens VC-A52S Installation Guide

English - 30
Motionless
Preset
On / Off
When the function is
enabled, the screen will
Freeze when Preset is
executed. Freeze will be
released after Preset is
completed.
Control Port
RS-232C/RS-422
Choose whether the
control interface used is
RS-232C or RS-422
Protocol
VISCA / Pelco D
Baud Rate
9600/38400
Choose the transmission
speed of the control signal
VISCA
Address
0~7
Pelco D
Address
1~ C~255
The Protocol set to Pelco
D allows the camera ID
address to be assigned
Output Mode
1. 1920x1080/60p
2. 1920x1080/50p
3. 1920x1080/30p
4. 1920x1080/25p
5. 1920x1080/60i
6. 1920x1080/50i
7. 1280x720/60p
8. 1280x720/50p
9. 1280x720/30p
10. 1280x720/25p
11. 1080/59.94p
12. 1080/59.94i
13. 1080/29.97p
14. 720/59.94p
15. 720/29.97p
Choose the output
resolution
Factory
Reset
On / Off
Resume the factory
default setting
Status
Display the current setting
status

Lumens VC-A52S Specifications

General

Power	DC 12V
Sensor Type	CMOS
Video Output	HDMI
Control Interface	RS-232
Effective Pixels	2.07MP
Lens Type	Zoom
Focal Length	4.7mm
Aperture	F1.6-F3.5
Day/Night	Yes
Minimum Illumination	0.5 lux (F1.6)
Video Compression	H.264, MJPEG
Network Interface	RJ-45 (10/100Mbps)
Power Supply	DC 12V
Resolution	1920x1080 (Full HD)
