English - 17
Chapter 7 DIP Switch Setting
7.1 OUTPUT SWITCH
The factory default is MENU (depend on the setting menu), and the default resolution of the
setting menu is 1080p60
The camera will restart 5 seconds after modifying the DIP
To switch via the OSD/ RS-232 Command is also available based on the last executed
action
USB and IP may only choose one, because they cannot be output at the same time
The Ethernet mode only defines the highest output frame rate of the streaming, but not
determines the resolution and frame rate of the streaming
Ethernet mode determines the output resolution and fps of HDMI/SDI
<Description> When all DIP are set to ON, the video resolution of the camera is
determined by the setting menu
