Lumens VC-TR1 User Manual

English - 19
Appendix 1
1. Output specification table
HDMI/SDI
IP Stream (LumensCMS setting)
USB
IP Stream
Resolution
Resolution
FPS
1080P60
PTZ Main stream
1080P / 720P / D1 / QVGA
1920*1080
1280*720
640*480
320*240
30
Panoramic stream
1080P / 720P / D1 / QVGA
Preview stream
720P / D1 / QVGA
1080P50
PTZ Main stream
1080P / 720P / D1 / QVGA
1920*1080
1280*720
640*480
320*240
25
Panoramic stream
1080P / 720P / D1 / QVGA
Preview stream
720P / D1 / QVGA
1080P30
PTZ Main stream
1080P / 720P / D1 / QVGA
1920*1080
1280*720
640*480
320*240
30
Panoramic stream
1080P / 720P / D1 / QVGA
Preview stream
720P / D1 / QVGA
720P60
PTZ Main stream
1080P / 720P / D1 / QVGA
1280*720
640*480
320*240
30
Panoramic stream
1080P / 720P / D1 / QVGA
Preview stream
720P / D1 / QVGA
720P50
PTZ Main stream
1080P / 720P / D1 / QVGA
1280*720
640*480
320*240
25
Panoramic stream
1080P / 720P / D1 / QVGA
Preview stream
720P / D1 / QVGA
2. Function descriptions of special preset: Special preset cannot be used as general preset
Special preset
Function
Remark
80
Start tracking
81
Stop tracking
95
Enter or exit the setting menu
96
Clear 0 - 64 preset
99
Reboot the machine
121
Output PTZ screen
HDMI/ SDI
122
Output panoramic screen
HDMI/ SDI
123
PTZ and panoramic PIP screen
HDMI/ SDI
