General
Packaging
- Ethernet-DMX8 MkII
• 1 x Ethernet – DMX8 MkII
• 1 x User guide
- Ethernet-DMX8/Truss MkII
• 1 x Ethernet – DMX8 MkII Truss
• 1 x Powercon male connector
• 1 x User Guide
Description
The Ethernet-DMX8 MkII is an Ethernet node that serves 8 x DMX512
outlets, compatible with the following protocols: DMX512, DMX512-A,
RDM (ANSI E1.20), sACN (ANSI E1.31) and Art-Net™.
All 8 outlets can be used as input or output. The Ethernet links are
100BaseTx connections on shielded Neutrik RJ45 Ethercon connectors.
All configuration can be done over Ethernet through a built in website, or
the front panel display.
This all comes in a 19'' unit high metal housing for the Ethernet-DMX8
MkII. The Ethernet-DMX8/Truss MkII comes in a rugged truss mountable
metal housing with two M10 inserts. This enclosure allows to use the node
in a truss, on a wall or as a table top device.
Specification
Dimensions
Ethernet-DMX8 MkII
482 x 183 x 44 (mm)
19” x 7,2” x 1,73”
Package: 520 x 235 x 50 (mm)
Ethernet-DMX8 MkII Truss
240 x 180 x 90 (mm)
9,44” x 7,08” x 3,54”
Package: 310 x 260 x 110 (mm)
Page 6 of 35 Ethernet - DMX8 MkII Range
