• Weight
Ethernet-DMX8 MkII: 2,3 kg
Ethernet-DMX8/Truss MkII: 3,1 kg
• Electrical
Ethernet-DMX8 MkII:
Voltages: 90 – 260 VAC
Frequency: 47 – 63 Hz
Rated power: 20 W
Fuse: 125V – 250V, 1A, Slow blow only (5mm x 20mm)
Ethernet-DMX8/Truss MkII:
Voltages: 100 – 240 VAC
Frequency: 50 – 60 Hz
Rated power: 20 W
Fuse: 250V 1A, Slow blow
• Connectors
2 x shielded Neutrik RJ45 Ethercon connector
(front and rear for Ethernet-DMX8 MkII, front and side for Ethernet-
DMX8 MkII Truss)
8 x shielded Neutrik gold plated 5 pin XLR (female)
8 x optic and galvanic isolated DMX port
1 x IEC inlet with fuse holder (Rack version only)
1 x Neutrik Powercon inlet (Truss version only)
• Environmental
Operating temperature: 0 ~ 60°C (32 ~ 140°F)
Storage temperature : -10 ~ 70°C (14 ~ 158°F)
Humidity: 5-95% non condensing
Ethernet - DMX8 MkII Range Page 7 of 35
