LX7000 Mar.2002
Page 13
TP-SORT
The LX 7000 is able to sort the turnpoints under alphabet or under distances (some kind of NEAR TP function).
Being sorted under distance the nearest TP will appear, after starting of select procedure.
3.1.2.2 OBS. ZONE (observation zone)
Following confirmation procedures can be defined:
• Start zone
• Turnpoint confirmation procedure
• Finish procedure
• FAI photosector or cylinder templates
START ZONE
All procedures can be defined using two angles and two radiuses (A1, A2, and R1, R2). With HDG the orientation is
described. Angle A21 is by some settings defined automatically (AUTO) and sometimes it is free.
Combination of photo sector and cylinder
TO NEXT PNT: orientation to the next TP (A21 is auto)
R.FROM 1.TP: radius from 1. TP going through start point. The start line is like a circle segment.
Example R.from 1. TP
A21 doesn’t matter, A1 doesn’t matter, R1 circle segment in km, A2 doesn’t matter, R2 brightness of the sector
in km
FIXED VALUE: free programmable through A21
