LX7000 Mar.2002
Page 15
3.1.2.4 UNITS
Practically all known units and combinations can be used in the LX 7000.
• LAT, LON: decimal minutes or seconds
• DIST: km, NM, ml
• SP (speed) km/h, kts, mph
• VARIO: m/s, kts
• HDG: magnetic or true
• WIND: km/h, kts, mph, m/s
• ALTITUDE: m, ft
• QNH: mb, mm, in
• OVERLOAD: kg/m2, lb/ft2
Glider + Pilot + Ballast
OVERLOAD= --------------------------------
Glider + Pilot
Example:
Overload 1.2 means that the take of weight is 20% higher than unballasted.
3.1.2.5 GRAPHIC
The graphic display of the LX 7000 offers valuable information, selected by the user. In order not to overload the
display some care should be taken by enabling of airspace.
SYMBOL
The LX 7000 graphic supports two sizes of glider symbol in graphic. Rotate v to select the symbol.
