LX7000 Mar.2002
Page 22
3.2.1 GPS page
There are no settings possible in this page.
Rotate v and both altitudes (m and ft) will appear on the same screen.
Stop watch can be activated and deactivated under following procedure:
• Press START status STOP: 0: 00
• Press START status RUN: 0:12
• Press START status STOP: 0:50
• Press START status STOP: 0:00 Reset
• Press ENTER TIME: 11:56:32 Time again
3.2.2 NEAR AIRPORT
The nearest airports will be shown using this mode. The airports are separated under distance and simple press on
ENTER will change over to APT mode and all nav. features will be immediately present. To select the airport use
v.
IMPORTANT!
Not only airports are in the library, but all landable turnpoints too. The airports and landable turnpoints are
displayed with different symbols in front of the name. For more information see paragraph turnpoints.
Battery voltage ind 11V empty
Airfied from TP database
Outlanding place
Airfied from APT database
