LX7000 Mar.2002
Page 24
The glider symbol is all the time in the middle of the screen and the map is moving. To change the ZOOM simple
rotate the ZOOM knob left or right. Following nav. page can be disabled like Nav. page 3.
ETA estimated time of arrival
ETE estimated time enroute
If there is no way to reach point (difference BRG/TRK more than 90°), both times will be replaced with stars.
The last page shows the pilot some important airport data.
The traffic circuit is defined like altitude and orientation (N, E…). Orientation I means that it hasn’t been defined.
RWY extension shows runway surface, G like grass and C like concrete.
Groundsp.
ZOOM
Estimated time enroute
Battery voltage
Estimated time of arrival
