Fault Codes
Fault
Code
(Hex)
Name
Description
Repair Action
13
Redun
dant
Lid
Unlock
ed
In spin mode, the lid
switch feedback has
voltage (lid closed), for
more than 5 seconds
the motor speed
feedback assumes the
basket is spinning > 4-
5 RPM when the lid
lock feedback has no
voltage (Lid
Unlocked). Lid Switch
Feedback has no
Voltage when the
BRPM is > 4-5 RPM.
 Check lid switch continuity at J513 on the
control.
 Check continuity of lid lock position. Opened
or Closed.
 Check for proper operation of lid lock, 120
VAC while activating.
 Check lid lock wiring harness from the
control to lock assembly.
 If lid lock assembly and harness are OK,
replace control board.
14
Lid
Lock
Failure
Signal received by
control is indicating the
lock will not lock or
unlock when
requested or the lid
switch is indicating
open when the signal
received indicated
locked.
 Verify that the lid lock is not blocked by any
external debris.
 Check lid switch continuity at J513 on the
control.
 Check continuity of lid lock position. Opened
or Closed.
 Check for proper operation of lid lock. 120
VAC while activating.
 Check lid lock wiring harness from the
control to lock assembly.
 If lid lock assembly and harness are OK,
update the software.
15
Water
Temp
Sensor
invalid
1. Thermistor
disconnected/not
present.
2. Failed Thermistor
 Check thermistor resistance from connector
J701 on the control board. Validate the
resistance matches the table in mini-manual.
 Check wiring harness and connectors.
 Replace thermistor
