DIAGNOSTIC INFORMATION
Overview
Diagnostic Information provides diagnostic, repair, and reset information for the selected vehicle.
Active
Search Google for ...
2007
Engine
Jeep
OBD-II
Select Vehicle
Tue, 10 May 2016
Unlimited
Wangler
Jeep
CHECK
CHECK
101001
1001
0101
2:59
Read DTCs Data Stream Special Tests
Diagnostic
Information
SettingsBrowserMaintenance Tests
All System DTC
Scan
Automated System
Test Veiw Saved Tests
View Data Stream
Recordings
System Wiring
Diagrams
ss02502
1. Select Diagnostic Information from the home screen.
Diagnostic Information
2007
Jeep
Code-Assist Library
138
2 85
Wrangler
Unlimited Rubicon 3.8
Current
ENGINE
Direct-Hit® Repair-Trac® Symptom Assist
Symptom List Video Library Drive Cycle Oil Light Reset
PCM Pin TSB Reference Trans Pan ID Location Info
+
!
_
1 3 5
2 4 R
ss02503
2. Select the desired function from within the Diagnostic Information menu.
AutoDetect Results Number Indication
Diagnostic Information provides diagnostic, repair, and reset information for the selected vehicle.
• Each vehicle and controller will have its own set of indications.
• The indication is displayed on top of the Diagnostic Information selection.
• When entering diagnostic information, the application will conduct a search in the background for the
selected vehicle/controller combination to determine the number of items it will contain.
NOTE: If diagnostic information is desired for a different controller or vehicle, return to the Home Screen and
change the controller or vehicle there, then re-select Diagnostic Information. Failure to follow this could lead to
display errors or communication errors.
NOTE: Not all assets within the Diagnostic Information menu will utilize the AutoDetect Results Number indi-
cation feature.
