Tune Up Specifications
Provides specifications for specific components when a tune up is performed.
1. Select Tune Up Specs from the Diagnostic Information screen.
Tune Up Specs
Injector
Starter
Specification: 11 to 18 Ohms
Regulator
Timing
Spark Plug
Firing Order
Battery
2004
Ford
F-150
XL 5.4
Current
ABS (RABS)
ss02519
2. Some of the tune up specifications contained in this section include the following:
• Starter
• Generator
• Regulator
• Spark plug
• Idle speed
• Fuel pressure
• Compression
• Firing order
Key Programming
Displays instructions for the selected vehicle for programming a key.
1. Select Key Programming from the Diagnostic Information screen.
Key Programming
Battery Location
Battery Replacement
Pressing the LOCK button once locks all doors and activates the alarm system (if fitted).
Pressing the LOCK button twice within 3 seconds confirms all doors locked by sounding the horn once.
Pressing the UNLOCK button once deactivates the alarm system (if fitted) and unlocks the driver’s door
Pressing the UNLOCK button twice within 3 seconds deactivates the alarm system (if fited) and unlocks
Pressing the panic button once activates the panic alarm. The horn will sound and the parking lamps will
Pressing the panic button agiain, of turning ignition ON deactivates the panic alarm.
Remote transmitter added or replaced.
System Malfunction.
Obtain all remote transmitters.
Switch ignition from OFF to ON 8 times within 10 seconds:
Doors should lock then unlock.
Within 20 seconds:
Press any button on the first remote transmitter.
Doors should lock then unlock.
The horn will sound twice if a door is open
only.
all doors.
flash
System Operation
Programming
When
How
Remote Alarm/Central Locking
Immobilizer
1
22
fig107944
3
1
4
3
2004
Ford
F-150
XL 5.4
Current
ABS (RABS)
ss02520
2. Follow the prompts on the screen to program a key and or replace battery in key.
