215505 10 Revision A
3.1 FD230, Double Reel, Five and Six Bats – Narrow
$
%
&
'
(
Figure 3.1: Left Side Narrow
1 - MD #137092 2 - MD #311321 3 - MD #220941 4 - MD #273052
A - MD #108172 B - MD #184584 C - MD #135800 D - MD #137118 E - MD #30228
$
%
$
%
Figure 3.2: Right Side Narrow
1 - MD #137092 2 - MD #311324 3 - MD #220941 A - MD #137118 B - MD #30228
