215505 34 Revision A
5.2.1 Installing Reel Endshields at Outboard Cam End
This procedure is applicable to the outboard cam end on all reel configurations.
To install the cam end (outboard) endshield (A), follow these steps:
NOTE:
The endshield segments used for this procedure have two additional holes (B) on one end. Do NOT confuse them with the
segments (C) used for the outboard tail end of the reel.
NOTE:
The arrow points to the front of the machine.
$
&
'%
Figure 5.24: Five-Bat Reel – Endshield, Cam End, Outboard
INSTALLATION INSTRUCTIONS
