215505 13 Revision A
3.4 FD235, Double Reel, Five and Six Bats – Wide
$
%
&
'
(
'
(
'
(
Figure 3.7: Left Side Wide
1 - MD #137092 2 - MD #311321 3 - MD #311324 4 - MD #311323 5 - MD #220941 6 - MD #273052
A - MD #108172 B - MD #184584 C - MD #135800 D - MD #137118 E - MD #30228
$
%
$
%
$
%
Figure 3.8: Right Side Wide
1 - MD #137092 2 - MD #311324 3 - MD #311323 4 - MD #220941 A - MD #137118 B - MD #30228
STEEL FINGER PLACEMENT
