Flex vs Float – When to Lock and Unlock
Table of Contents
Ø Always Lock for Road Transport.
Ø Can be Either Locked or Unlocked in the Field.
Ø 2 Latches - Each Wing Locks Independently.
Ø Each Wing Flexes Independently.
Ø Reel Flexes with Cutterbar to Maintain Close
Consistent Relationship With Knife.
Ø Always Lock for Road
Transport.
Ø Always Unlock in the Field.
Ø 2 Latches to Lock/Unlock – One
on Each side of Adapter
Ø When Properly Set, Header
Floats off of Adapter to Lightly
Follow Terrain.
Float
Refers to Flexing of the 3 Piece Header Frame
Refers to Separation (or Float) Between Adapter and Header
