MacDon FlexDraper FD75 - 100 Hour Service Interval; 100 Hours (Check Fluids); 100 Hour (Greasing)

100 Hour Service Interval
Draper Clinic Handout
7
100 Hours (Chains)
• Every 100 hours or less- check and adjust
tension on rotating feed drum drive chain (A)
and reel drive chain (F). Follow procedure in
Maintenance and Service section of Operator’s
Manual to remove and replace chain covers.
Liberally apply grease to both drive chains.
Find your operators manual at: www.macdon.com/support/operators-manuals
100 Hour (Greasing)
A - Float Pivot- RH & LH
B & D - Float Spring Tensioners
(2 on each side)
C - Upper Cross Auger - if
equipped (1 Place)
E- Driveline Guard (2 Places)
100 Hours (Check Fluids)
Remove plug (B) and check oil level
in knife drive gearboxes (A).
Check oil level in main drive gearbox
at location (D).
Please Refer to Maintenance and Servicing Section of Operators Manual for Model Specific Maintenance
