SM1 Bluetooth GNSS Receiver
Specifications:
● GPS-, GLONASS-, SBAS-,
QZSS-signals
● 10 Hz update rate
● Absolute accuracy: 2.5 m CEP
● Absolute accuracy with SBAS
correction: 2.0 m
● Absolute accuracy with SBAS +
PPP correction: < 1 m
● Pass-to-pass accuracy with
SBAS+PPP correction:10-20 cm
● Speed accuracy: 0.1m/s
● Hot start TTFF open sky: 29 mp
● Col start TTFF open sky:30 mp
● Sensitivity: -161 dBm
● Bluetooth device name:
MachineryGuide BT-REC-V2.3
DM1
When the Receiver is turned on, after two-three minutes of initialization time
(depends on the satellite coverage) the Receiver starts to provide submeter
level pass-to-pass accurate position data.
DM1 Bluetooth GNSS Receiver
Specifications:
● Uses GPS, GLONASS, SBAS,
QZSS signals
● 10 Hz update rate
● Absolute position accuracy 2.5
m CEP
● Relative (pass-to-pass)
accuracy: 30-40 cm
● Velocity accuracy 0.1m/sec
● Warm start TTFF under open
sky 29 sec average
● Cold start TTFF under open sky
30 sec average
● Tracking sensitivity -165 dBm
● Bluetooth device name:
MG BT-REC-V2.3
When the Receiver is turned on, after ten minutes of initialization time
(depends on the satellite coverage) the Receiver starts to provide decimeter
level pass-to-pass accurate position data.
