Steps of starting navigation:
1. Go through the steps of ”Starting a new job session”.
2. Drive the agricultural machine to the right position, if the machinery is not yet
at the area to be cultivated
3. Tap “Start” to start the job.
In case of A-B guidancing, User has to select a reference section, to which the
navigation path (parallel lines) will be calculated. For setting the reference line, “A” and
“B” points have to be placed.
4. Set point “A” to set the first reference point
5. Drive forward. To place ”B” reference point the machinery need to be at least
20 metres away from point ”A”. Until then, ”B” button is inactive.
6. Set point “B” to set the second reference point
7. Guidancing now has started. It can be interrupted any time by tapping the
button, and be continued by tapping the button.
8. Go by the outlined navigation lines, follow the directions of the navigation
arrow.
