Specifications:
● Uses GPS, GLONASS, SBAS,
QZSS signals
● 10 Hz update rate
● Absolute position accuracy 1
cm CEP
● Relative (pass-to-pass)
accuracy: 2 cm
● Velocity accuracy 0.1m/sec
● Warm start TTFF under open
sky 29 sec average
● Cold start TTFF under open sky
30 sec average
● Tracking sensitivity -165 dBm
● Bluetooth version: 2.0
● Bluetooth device name:
● MG BT-REC-V2.3
When the Receiver is turned on, after ten minutes of initialization time
(depends on the satellite coverage) the Receiver starts to provide
centimeter level pass-to-pass accurate position data.
DM1 and CM1 antennas could be
connected to the Bluetooth GNSS
Receiver via an RF cable.
● Length: 2.5 m
