The DM1 antenna can be installed with a
magnetic console. The antenna goes to
the top of the holder.
The consol with the antenna should be
installed to the top of the agricultural
machine. It is very important to place it
on the highest part of the vehicle, and to
ensure that it is not covered, because
this is indispensable to achieve the
correct pass-to-pass accuracy.
The DM1 antenna has high gain (40 dB)
and multipath error rejection.
Specifications:
● Frequency: 1574 MHz ~ 1606
MHz
● Bandwidth: 31 MHz (1dB)
● Polarization: RHCP
● Antenna gain: 40 dB
● Size:152 mm x 152 mm x 94
mm
● Connector: TNC
● Manufacturer: Harxon
The receiver unit gets the 12 V supply via DC cable. The communication with the
tablet is done via Bluetooth interface. The external GPS antenna can be connected to
the receiver via an SMA-connector. The data connection is in the form of serial NMEA
messages.Two GNSS Receiver options available for the MachineryGuide application:
